KX6 Video 75 Ohms
CABLE CONSTRUCTION
Conductor | Stranded bare copper | 7*0.20 ±0.005 mm |
Insulation | Solid PE | 3.70 ±0.10 mm |
Shield | Aluminum alloy braid 16 x 6 x 0,12mm | 80% |
Sheath | PVC | 6.10±0.10 mm |
Color | Green | |
Bending radius | ≥ 8 x Diameter (mm) Installation | |
Storage temperature | -15ºC + 70ºC | |
DESCRIPTION
Used as a distribution cable for indoor CATV, CCTV system and as a connection cable for satellite system where lower attenuation required.
ELECTRICAL SPECIFICATIONS
Attenuation at 20°C MHz | dB/100 m |
10 | 5 |
50 | 8.1 |
100 | 13.0 |
200 | 18.5 |
400 | 22.5 |
800 | 34.5 |
950 | 37.5 |
1000 | 45.0 |
