305m Reel Coaxial Cable 50 Ohm Impedance Solid PE Insulation RG316 Basic Info
Model NO: RG316
Conductor Material: CCS/CU
Conductor Type: Stranded
Certification: CE, ISO, CCC, UL, VDE
Brand: OEM
Center Conductor: 7*0.17+0.01mm Strand Bare Copper
Jacket: 2.49+0.05mm FEP
Transport Package: 100m, 305m, 500m, 1000m Wooden / Plastic Reel
Origin: China
Application: Coaxial Cable
Material Shape: Round Wire
Wire Core Material: Bare Copper Wire
Electrical Characteristics:
Impedance(Ohms) | 50±3 @1-400MHz |
Nominal Capacitance(PF/m) | 101 @1KHz |
Velocity of Propagation | 66% |
Attenuation[ @68°F]:
Frequency (MHZ) | Maximum(dB/100M) |
1 | 0.6 |
10 | 2.0 |
50 | 4.9 |
100 | 6.9 |
200 | 9.8 |
400 | 15.4 |
Our Services:
1. Free sample
2. We can suggest you our suitable products when u have no idea about the cable
3. If available for you, welcome to visit our factory
4. We can according to your samples to produce exactly the same product
5. If our customer have any problem, we will reply at 24 hours
Company Information:
Hanyang(Hangzhou)Cable.Ltd.belongs to the Superlink Holding Limited ,which established in1990, located in Lin'an Hangzhou City. ''Super Link'' is our brand name. We are the member of the IWMA specializes in the production of cable, such as coaxial cable, network cable, speaker cable, etc.
