Single Copper Foil Fire Alarm Cable
Single Copper Foil Fire Alarm Cable
Technical specifications:
Number of Cores | Constructions | Material | OD |
2 | Conductor | BARE COPPER (BC) | 0.80mm |
Dielectric | PVC/FR-PVC/ LSOH | 1.6mm | |
Jacket/Sheath | PVC/FR-PVC/LSOH | 4.6mm |
Application:
Fire alarm cables are for use with fire monitoring/detection, fire alarm systems, audio circuits, fire protective circuits, control circuits, smoke detectors, signaling and security systems
Recommended Packing:
Inner: Roll,Coil,plastic reel, Wooden Spool, plastic reel
Outer: Box, Carton, Pallet
Length: 100m, 200m, 305m,500m, 100ft, 300ft, 1000ft or more
Electrical and Mechanical Characteristics (@20℃):
Nominal Voltage of Operation | 300 Volts (max. ) |
Nominal Temperature of Operation | -15℃ up to +70℃ |
DC Resistance of inner conductor | ≤3.5Ω per 100m |
DC Resistance of Insulation | ≧0.010Ω per km |
Note: the testing results will be changed if the specifications of the cable changes. | |
