EV Power Battery Electric Electrical Charging Wire Cables
Nominal voltage: 1000V
Temperature range: -40º C-+200º C
O. D. Tolerance: ± 0.1mm
Send Inquiry
Product Details ofEV Power Battery Electric Electrical Charging Wire Cables
Product Description
EV unshileded insulated silicone cable dw25
Nominal voltage: 1000V
Temperature range: -40º C-+200º C
O. D. Tolerance: ± 0.1mm
Conductor:Annealed bare copper wire
Insulator: Silicone rubber.
Color:orange
Company profile
we are a professional cable and materials manufacturer from china with 15years of production experience. we have own factory, in hangzhou china and Hanoi Vietnam. we produce coaxial cable, network cable, patch cord, speaker cable, alarm cable, control cable, power cable, fiber cable, fiber patch cord, RJ45 Connector etc. And materials, like CCA, ALMG,CCAM
Structural parameter table
Category | Wire specifications | Reference current (A) | Diameter unshielded (mm) | |
| TPE | PU | |||
EV-(R)SS,EV-(R)SSPS,EV-(R)S90S90,EV-(R)S90S90PS90,EV-(R)S90U,EV-(R)S90S90PU-450/750V | 3×2.5+2×0.75 | 18 | 12.7 | 11.1 |
| 3×4+2×0.75 | 25 | 14.4 | 12.8 | |
3×6+2×0.75 | 34 | 16.3 | 14.5 | |
5×2.5+2×0.75 | 18 | 15.3 | 13.7 | |
5×4+2×0.75 | 25 | 17.8 | 16.0 | |
5×6+2×0.75 | 34 | 19.8 | 17.8 | |
5×10+2×0.75 | 50 | 22.9 | 20.7 | |
5×16+2×0.75 | 67 | 27.5 | 25.1 | |
