50 Ohm 5C-FB Coaxial Cable
Application:
Drop cable for CATV, MATV distribution and satellite applications.
Construction:
Inner Conductor | 1.05+0.01mm Bare Copper |
Dielectric | 4.80+0.05mm Foam PE |
Foil Shield | Al Foil |
Braid Shield | Tinned Copper 85% coverage |
Jacket | 7.0+0.05mm PVC |
Jacket Thickness | 0.5mm |
Electrical Characteristics:
Capacitance | 81 ±3 pF/m |
Impedance | 50± 3 Ω |
Return loss | 5 ~2300MHz > 20dB |
Velocity of Propagation | 82% |
Sparker Test (VAC) | 3000V |
Attenuation(20℃)
Frequency(MHz) | Attenuation(100M) |
150 | 7.8 |
200 | 9.1 |
280 | 10.9 |
350 | 12.2 |
400 | 13 |
800 | 18.9 |
900 | 20 |
1200 | 24 |
1500 | 27.2 |
1900 | 31.3 |
2000 | 32.5 |
2400 | 35.8 |
3000 | 40.9 |
