Indoor UTP CAT6 Cable
Specification
Conductor Size | 23AWG |
0.56mm | |
Conductor Material | CCA/BC |
Number Of Conductor | 4P |
Shiled | UTP/FTP/STP/SFTP |
Flammability Grade | CMP, CMX, CM, CMG, MPG, CMR, MPR |
Indoor / Outdoor | Single Jacket/Double Jacket |
Insulation Material | PE, HDPE, LSZH PE |
Insulation Thickness | 0.91mm |
Jacket Material | PVC, RoHS PVC, LSZH PVC |
Outer Jacket Thickness | 5.6mm |
DC Resistance(Max. ) | 9.5 Ohm/100M |
DC Resistance Imbalance | 2.50% |
Working Capacitance(Max. ) | 5.4NF/100M |
Insulation Resistance | 10000 MOhm. Km |
Transmission Velocity | 65% |
Operating Temperation | -40 °C - +75 °C |
PVC Jacket Color | As Client's Request. |
Electrical Characteristic:
1.0-100.0MHz Impedance (ohms): 100 +/- 15
1.0-350.0MHz Delay Skew (ns/100m): <=45
Pair-to-Ground Capacitance Unbalance (pF/100m): <=330
Max. Conductor DC Resistance 20 degree(ohms/km): 93.8
Resistance Unbalance (%): <=5
Working Temperature: -5° C~+50° C
Storage Temperature: -20° C~+60° C
Terms:
1.OEM is welcomed
2.ISO/CE/ETL/ROHS/UL/SONCAP and other certifications are available
3.Competitive price and high quality offered.
4. Best service for you!
